Our biggest kiln yet! The 120L is built to expand your firing capabilities and flexibility, our most efficient and high-performance kiln! This kilns max temperature is 1280C thanks to its hi-fire elements but we recommend keeping firing below 1260C to extend overall lifespan. Weight total 80KG. Pallet shipping available. Please specify is tail-lift is required as this incurs an additional $100 shipping fee.
Key features of the 120L Kiln
50mm 1450 grade composite insulation (usually reserved to industrial applications) + 50mm backup AES blanket
Front loading for ergonomic loading and unloading with minimal shop footprint.
Marine grade 5032 Aluminium housing for corrosion resistance and portability
Kanthal A1 elements with extra-low loading
Actively cooled control base
Lid + Door bungs allow viewing and faster cooling
Door safety switch
Dual SSR’s for extra safety and overfire protection
2 year warranty (elements and thermocouple excluded)
Made with passion in: AUSTRALIA
The included TMCON controller features numerous digital technologies such as AI driven PID temperature tuning for high accuracy as well as a total of 80 steps or 8 programs with 10 steps. Perfect for educational and professional applications.
Optional Bartlett controller upgrade features an included library of numerous common firing profiles, it is the standard controller used on many well known brands of kilns such as L&L kilns. This controller comes with wifi connectivity for updates and monitoring of firing. More info on Bartlett's page: https://www.bartlettinstrument.com/product/genesis-spark
Specifications:
Firing capacity: 120 litres
Maximum Temperature: 1280C
Chamber dimensions: 41cm wide, 58cm deep, 50cm high
External dimensions: 61cm wide, 75cm deep, 90cm high
Shelf Dimensions: 30cm wide, 50cm deep, 2cm thick
Weight: 70kg
Power: 7.2kW
Supply: 32A fused
Amp draw: 30A
Controller: TMCON or Bartlett
120L furniture kit:
- 300x500x20mm hollow cordierite shelves x 4
- 30x100 props x 12
- 30x150 props x 4
- 30x50 props x 4
- 3kg kiln wash
